1. Power grid, PV, battery power supply priority can be set;
2. Built -in timer for switching operations in multiple modes;
3. Support WiFi/4G multiple communication methods, check the system running status anytime, anywhere;
4. Extensible lithium battery design, 20-40kWh lithium battery optional, meet the daily electricity needs of users;
5. Self-sufficiency, Off-grid hybrid inverter;
6. Pure sine wave output, Friendly to electric equipment;
7. System IP65 rainproof design, environmentally friendly, ultra -mute design.
| Specifications and models (Inverter) | TG-8KH3E | TG-10KH3E | TG-12KH3E | ||
| PV Input Parameter (DC) | |||||
| Maximum PV Input Power (KW) | 10.4KW | 13KW | 15.6KW | ||
| Maximum DC Voltage（Ｖ） | 1000V | ||||
| Single MPPT Maximum Input Current（A） | 12.5A | ||||
| MPPT Voltage Range（V） | 180~850V | ||||
| Number of MPPT/Number of Parallel MPPT Components | 2/1 | ||||
| Output Parameter(AC) | |||||
| Rated Power（ KW) | 8.8KW | 11KW | 13.2KW | ||
| Rated Output Current (AC) | 12.7A | 15.9A | 19.1A | ||
| Rated Output Voltage（V） | 400/360-400 | ||||
| AC Output Frequency | 50/60Hz | ||||
| Power Factor | 0.8cap~0.8ind | ||||
| THDI | <3% | ||||
| Type of Grid | 3W+N+PE | ||||
| Emergency Power Output（ EPS） | |||||
| Rated Output Power（ KW) | 8.8KW | 11KW | 13.2KW | ||
| Rated Output Voltage（V） | 400V | ||||
| Rated output current (AC) | 12.7A | 15.9A | 19.1A | ||
| AC Output Frequency | 50/60Hz | ||||
| Auto Switch Time（ms） | ≤20ms | ||||
| THDI | <2% | ||||
| Overload Capability | 110%,60S/120%,30s/150%,10s | ||||
| General Parameters | |||||
| MPPT Efficiency (%) |
99.50% | 99.50% | 99.50% | ||
| Eu Efficiency (%) | 97.20% | 97.50% | 97.50% | ||
| Maximum Efficiency (%) | 97.90% | 98.20% | 98.20% | ||
| Battery Charging and Discharging Efficiency (%) | 96.60% | 96.70% | 96.80% | ||
| Shutdown Power Consumption (W) | ≤3W | ||||
| Noise (dB) | ≤35dB | ||||
| Battery Specification | |||||
| Nominal Voltage（V） | 204.8 | 256 | 307.2 | 358.4 | 409.6 |
| Battery Capacity（Ah） | 100Ah | 100Ah | 100Ah | 100Ah | 100Ah |
| Storage Energy Capacity (KWh) | 20.48 | 25.6 | 30.72 | 35.84 | 40.96 |
| Maximum Charging and Discharging Current | 50A | ||||
| Battery Cycle Life | 4000Cycles(80% DOD) | ||||
| System Parameter | |||||
| Operating Temperature Range | -20 ~ 60°C | ||||
| Ambient Humidity Range | 0-95% | ||||
| Size (H*W*D) mm | 1044*778*582 | 1196*778*582 | 1348*778*582 | 1500*778*582 | 1652*778*582 |
| Weight (kg) | 280kg | 325kg | 370kg | 420kg | 470kg |
| Communication Mode | WIFI/4G | ||||
